Sanyo PLC-XU101 User Manual

3
Table of Contents
Tr ademarks
Each name of corporations or products in this book is either a registered trademark or a trademark of its respective
corporation.
Features and Design . . . . . . . . . . . . . . . . . . .2
Table of Contents . . . . . . . . . . . . . . . . . . . . . .3
To the Owner . . . . . . . . . . . . . . . . . . . . . . . . .4
Safety Instructions . . . . . . . . . . . . . . . . . . . .5
Air Circulation 6
Moving the Projector 6
Installing the Projector in Proper Directions 7
Compliance . . . . . . . . . . . . . . . . . . . . . . . . . .8
Part Names and Functions . . . . . . . . . . . . . .9
Front 9
Back 9
Bottom 9
Rear Terminal 10
Top Control 11
Remote Control 12
Remote Control Battery Installation 13
Remote Control Operating Range 13
Installation . . . . . . . . . . . . . . . . . . . . . . . . . .14
Positioning the Projector 14
Adjustable Feet 14
Connecting to a Computer 15
Connecting to Video Equipment 16
Connecting to Component Video Equipment 17
Connecting the AC Power Cord 18
Basic Operation . . . . . . . . . . . . . . . . . . . . . .19
Turning On the Projector 19
Turning Off the Projector 20
How to Operate the On-Screen Menu 21
Menu Bar 22
Zoom and Focus Adjustment 23
Sound Adjustment 23
Remote Control Operation 24
Computer Input . . . . . . . . . . . . . . . . . . . . .26
Input Source Selection 26
Computer System Selection 27
Auto PC Adjustment 28
Manual PC Adjustment 29
Image Mode Selection 31
Image Adjustment 32
Screen Size Adjustment 33
Video Input . . . . . . . . . . . . . . . . . . . . . . . . . .35
Input Source Selection (Video, S-Video) 35
Input Source Selection (Component,
RGB Scart 21-pin) 36
Video System Selection 37
Image Mode Selection 38
Image Adjustment 39
Screen Size Adjustment 41
Setting . . . . . . . . . . . . . . . . . . . . . . . . . . . . .42
Setting 42
Maintenance and Cleaning . . . . . . . . . . . . .51
Warning Indicator 51
Cleaning the Filter 52
Resetting the Filter Counter 52
Slide Shutter 53
Cleaning the Projection Lens 53
Cleaning the Projector Cabinet 53
Lamp Replacement 54
Resetting the Lamp Counter 55
Appendix . . . . . . . . . . . . . . . . . . . . . . . . . . .56
Troubleshooting 56
Menu Tree 58
Indicators and Projector Condition 60
Compatible Computer Specifications 61
Technical Specifications 62
Optional Parts 63
Configurations of Terminals 64
Dimensions 64
PIN Code Number Memo 65

Sanyo PLC-XU101 Specifications

General

Matrix size	0.8 \
Vertical scan range	50 - 100 Hz
Horizontal scan range	15 - 100 kHz
Projection technology	LCD
Contrast ratio (typical)	500:1
Screen size compatibility	33 - 300 \
Projector native resolution	XGA (1024x768)
Keystone correction, vertical	±40 °
Output	D-Sub15 x 1
Video in	RCA x 1
Audio input	Yes
Aspect ratio	4:3
Dimensions (WxDxH)	334 x 232 x 78 mm
Connectivity technology	Wired
Lamp power	275 W
Light source type	Lamp
Noise level	29 dB
Dot clock scanning frequency	140 MHz
Audio (L/R) in	2
Headphone outputs	1
Display resolution	786 x 432 pixels
Power consumption (typical)	385 W

Weight and Dimensions

Weight	3500 g
