Sanyo PLC-XU101 User Manual

Dimensions
64
Appendix
Terminal : Mini DIN 8-PIN
1
2
3
4
5
8 7 6
SERVICE PORT CONNECTOR
R X D
-----
-----
GND
RTS / CTS
GND
GND
Serial
1
2
3
4
5
6
7
8
COMPUTER INPUT/COMPONENT INPUT/MONITOR OUTPUT TERMINAL (ANALOG)
Terminal : Analog RGB (Mini D-sub 15 pin)
5
1
2
34
10
9 678
15
14
13
11
12
Configurations of Terminals
Red (R/Cr) Input / Output
Ground (Horiz.sync.)
Green (G/Y) Input / Output
-----
Blue (B/Cb) Input / Output
Ground (Red)
Ground (Green)
Ground (Blue)
1
5
2
4
3
6
7
8
5V
Horiz. sync. Input/Output (Composite H/V sync.)
Ground (Vert.sync.)
DDC data
Ground
Vert. sync.
DDC clock
9
13
10
12
11
14
15
T X D
9.13 (232)
5.51 (140)
2.78 (70.5)
3.66 (93)
2.14 (54.3)
13.15 (334)
3.17 (80.5)
5.20 (132)
4.43 (112.5)5.08 (129)
8.9º MAX
Screw Holes for Ceiling Mount
Screw: M4
Depth: 0.472 (12.0)
Unit: inch (mm)

Sanyo PLC-XU101 Specifications

General

Matrix size	0.8 \
Vertical scan range	50 - 100 Hz
Horizontal scan range	15 - 100 kHz
Projection technology	LCD
Contrast ratio (typical)	500:1
Screen size compatibility	33 - 300 \
Projector native resolution	XGA (1024x768)
Keystone correction, vertical	±40 °
Output	D-Sub15 x 1
Video in	RCA x 1
Audio input	Yes
Aspect ratio	4:3
Dimensions (WxDxH)	334 x 232 x 78 mm
Connectivity technology	Wired
Lamp power	275 W
Light source type	Lamp
Noise level	29 dB
Dot clock scanning frequency	140 MHz
Audio (L/R) in	2
Headphone outputs	1
Display resolution	786 x 432 pixels
Power consumption (typical)	385 W

Weight and Dimensions

Weight	3500 g
