Computer Input
Move the red frame pointer to
the mode and press the
SELECT button.
The level being selected.
Image Select Menu
Image Select Menu icon
IMAGE button
Dynamic
Real
Image 1
Image 2
Image 3
Image Mode Selection
Image 4
Blackboard
(Green)
Standard
Remote Control
button
Normal picture mode preset on the projector.
Standard
Picture mode with improved halftone for graphics.
Real
For the image projected on a blackboard. See above for
further description.
Blackboard(Green)
For viewing with the user preset image mode in the Image
Adjust Menu (see page 33).
Image 1~4
For viewing pictures in a bright room.
Dynamic
Select the desired image mode from among Dynamic,
Standard, Real, Blackboard (Green), Image 1, Image 2,
Image 3, and Image 4 by pressing the IMAGE button on the
remote control.
Standard
Picture mode with improved halftone for graphics.
Real
Blackboard (Green)
Image 1–4
For the image projected on a blackboard.
This mode help enhance the image projected on a blackboard.
This is mainly effective on a green colored board, not truly
effective on a black colored board.
Dynamic
Direct Operation
For viewing pictures in a bright room.
Normal picture mode preset on the projector.
For viewing with the user preset image mode in the Image
Adjust Menu (see page 33). This Image memory is provided
in each computer, component, and video input source.
Press the MENU button to display the On-Screen
Menu. Use the Point 7 8 buttons to move the red
frame pointer to the Image Select Menu icon.
1
2
Use the Point ed buttons to move the red frame
pointer to the desired image mode and then press the
SELECT button.
Menu Operation
