Sharp LC-32LB261U User Manual

23
LC-32LB261U Sharp 32" LED TV
Connecting an MHL-enabled device
You can connect an MHL-enabled device, such as a cell phone, and view your device’s screen on your TV.
1 Connect the small connector on an MHL cable (not provided) to the micro USB port on the MHL-enabled device.
2 Connect the other end of the cable to the HDMI 2/MHL jack on the side of your TV.
3 Turn on the MHL-enabled device.
4 If your TV is turned on, press ENTER when a message appears. Your MHL-enabled device’s menu opens.
OR
If your TV is turned off, turn on your TV. Press HOME. Your MHL-enabled device’s menu opens.
Note
You must use the purple HDMI 2/MHL jack to connect an MHL-enabled
device.
Notes
You can also switch to MHL mode by:
• Pressing INPUT and selecting HDMI 2 (MHL)
• Pressing MENU and selecting MHL
For instructions on using your MHL-enabled device, see “Using an
MHL-enabled device” on page 43.
MHL cable
Side of TV
MHL-enabled
device
On your TV
HDMI cable
connector
HDMI 2/MHL
jack

Sharp LC-32LB261U Specifications

General

Screen Type	led
Wall Mount	100mm x 100mm
Screen Size	31.5 inches, 32 inches
Refresh Rate	60hz
Brightness	180 candela per square meter
Speakers Output	10 watts
USB Ports	1
RF Antenna	yes
Headphones Output	yes
Digital Optical Audio Outputs	1
Component Video Inputs	1
Composite Video Inputs	1
DVI	1
3D	no
Power Consumption	81 kilowatt hours
Depth with Stand	6.5 inches
Height with Stand	18.38 inches
Width with Stand	28.63 inches
Net Weight with Stand	11.3 pounds
Depth without Stand	2.5 inches
Height without Stand	17.13 inches
Net Weight without Stand	10.6 pounds
