Siemens 8DA10 Series User Manual

861-9601.9 • INSTALLATION AND OPERATING INSTRUCTIONS • 8DA10 • Revision 11 201/214
Operation
40 Cable testing
40.1 Safety instructions
40.2 Test voltage
Two possibilities for cable testing are described hereafter.
Test voltages
DANGER
Life-endangering high voltage
Can cause death, serious injury and property damage. DC voltage applied to the cable
and overvoltages at the busbar can cause flashover.
➭ Keep safety distances.
➭ Install barriers.
➭ Switch on warnings.
DANGER
High voltage and explosion hazard
If the voltage transformer is energized, or if it is of the non-disconnectable type,
the test voltage can destroy the voltage transformer and cause personal injuries.
➭ Switch disconnectable voltage transformers to EARTHED position before testing the cables,
and secure them.
➭ Remove non-disconnectable voltage transformers.
NOTICE
Voltage indicators may be damaged by test voltage during cable tests.
May cause property damage.
➭ Short-circuit the voltage indicators with short-circuit plugs at the earthing points of
the test sockets.
Rated voltage of the
switchgear [kV]
DC test voltage AC test voltage VLF
1
0.1 Hz
1
Very low frequency
Maximum value
[kV]
Test duration
[min]
Maximum value
[kV]
Test duration
[min]
7.2 22151160
12 38 15 19 60
15 52 15 28 60
17.5 52152860
24 72 15 38 60
25 72 15 38 60
36 72 15 57 60
38.5 72155760
40.5 72155760
CAUTION
Can cause injury or property damage.
Before starting the cable test, the suitability of the cables must be verified regarding
the selected test voltage.
➭ If a test duration different from the duration stated above is applied, please contact
the regional Siemens representative.
