Installation
50/214 Revision 11 • INSTALLATION AND OPERATING INSTRUCTIONS • 8DA10 • 861-9601.9
20 Transport and storage
20.1 Packing and transport unit
Transport unit Transport units consist of:
• Individual panels or panel groups consisting of up to 4 individual panels
• Accessories
Packing
The transport units can be packed as follows:
• On pallet, covered with film
• In a seaworthy crate (switchgear is sealed with desiccant bags in PE film)
• In a seaworthy crate with long-time packing
(switchgear is sealed with desiccant bags in aluminum-coated PE film)
• Other packing types in special cases (e.g. latticed crate)
20.2 Completeness and transport damages
Checking for
completeness
➭ Check whether the delivery is complete and correct using the delivery note and packing
lists.
➭ Compare the serial number of the switchgear panels on the delivery note with that on the
packing and the rating plates of the panels.
➭ Check whether the accessories are complete.
Checking for transport
damages
➭ Temporarily open the packing in a weatherproof place to detect hidden damages. Stick the
PE film together again and do not remove it totally until reaching the final mounting
position in order to keep the switchgear as clean as possible.
➭ Check the gas pressure.
➭ Inform the forwarding agent immediately about any defects or transport damages; if
required, refuse to accept the delivery.
➭ As far as possible, document larger defects and transport damages photographically;
prepare a damage report and inform your regional Siemens representative immediately.
➭ Have the transport damages repaired, otherwise you may not start installation.
➭ Refit the packing.
20.3 Intermediate storage
NOTICE
Disposal of packing and consumables
Incorrectly disposed of packings and consumables can pollute the environment.
➭ Packing and consumable materials of the switchgear must be disposed of in an
environmentally compatible way or recycled.
➭ Observe local regulations for disposal and environmental protection.
WARNING
Overloading of the storage space
Can cause serious injury. Can damage the storage place or the stored goods.
➭ Observe the load-bearing capacity of the floor.
➭ Do not stack the transport units.
➭ Do not overload lighter components by stacking.
