Siemens SICAM TM User Manual

Wiring for the Reception of Time Signals
SICAM TM, Installation 65
DC6-015-2.04, Edition 10.2014
5.3. LAN Time Server
NTP Server in 19" case for TCP/IP networks with integrated HTTP-Server. The internal
reference time is derived from a built-in GPS receiver of the type GPS167.
