5 Interfaces
Multifunctional Danger Control and Indicating Panels SIGMASYS C and M (M-Modules) 29 / 128
Best.Nr. A24205-A337-B970 – Edition 12 (03/07)
There are organisational and projected numbers for programming.
Organisational number: displayed on the operating panel and on the printer.
Projected number: required for internal processing and displayed on the printer.
The object number must have 3 digits and must be between 100 and 999. It is not possible to
assign a number twice (in SM88 and SIGMASYS). The projected number and the organisa-
tional number must be the same.
The organisational zone number must have 5 digits and is made up of the 3-digit object num-
ber and the 2-digit projected zone number.
The projected zone number must have 2 digits and must be between 01 and 99.
89 zones can be provided for each object.
Detector groups must always be entered with a projected number in the activation list for a
control module output (object/zone/detector group).
Example
Object ZONE Detector group Detector
Object org. 101
Object proj. 101
Zone org. 101 11
Zone proj. 101 11
Detector group org. ___ 1
Detector group proj. 0001
Control org. ___ 1
Control proj. 0001
Activation list MG 1 101 11 0001
Table 15: Programming in SIGMAPLAN
Object ZONE Detector group Detector
Object org. 101
Zone org. 101 11
Activation via zone
101 11
at the
printer
Detector group org. ___ 1
Control org. ___ 1
Activation via 101 11 0001
at the
printer
Table 16: Operating panel display
