Siemens SIGMASYS C User Manual

10 Programming of control facilities
Multifunctional Danger Control and Indicating Panels SIGMASYS C and M (M-Modules) 61 / 128
Best.Nr. A24205-A337-B970 – Edition 12 (03/07)
1
1
1
0
0
0
Programming of control facilities
10.1 Description of control pattern .............................................................................. 62
10.1.1 AL/LA – Alerting facilities..................................................................................... 62
10.1.2 EV – Evacuation alarm (internal alarm)............................................................... 63
10.1.3 Control facility (ST).............................................................................................. 63
10.1.4 Monitored control lines according to VdS via transponder SPF 3500 ................. 63
10.1.5 Display (ANZ)...................................................................................................... 64
10.1.6 Close-and-retain system (FSA) control facility and fire section control facility.... 64
10.1.7 Detector display and event display control pattern.............................................. 64
10.2 Freely configurable control parameters from V3.2 .............................................. 65
10.3 Overviev of control criteria................................................................................... 66
10.3.1 Control Pattern AL (alerting facility), EV (evacuation alarm, ANZ (display) ........ 67
10.3.2 Control Pattern ST (control facility) ..................................................................... 68
