Page #65 background image
9 Special control facilities
The alarm lines are switched to the slave MPC with the U-APL module (16 changeover con-
tacts) of the master MPC.
MPC2 cannot be installed at slot 6 of the SIGMASYS M control and indicating panel. The
standard cables supplied are too short. Slot 6 can be used in the M module in SIGMASYS M.
The following should be noted with Dual FDC FDnet connection
(Version 3.3 or above):
Only pure loops without T-tapping may be connected with a maximum of 63 elements.
Both modules must be available in release S24230-A103-A5 at least for dual MPC
operation.
9.1.1 Gas extinguishing systems
Control extinguishing command:
Smoke and flame detectors are to be connected in two-detector or two-zone dependency.
Two-zone dependency is preferable. Heat detectors can be connected in two-detector or two-
zone dependency.
Fire detector elements, such as fusible-link detectors, thermal isolators, immersion-type ther-
mostats do not need to be combined in two-detector or two-zone dependency.
To prevent inadvertent tripping, the control facility must be performed in conjunction with the
general alarm.
In the case of multi-zone extinguishing systems with only one message (“Fault, extinguishing
system”) for all extinguishing zones, the control pattern “ST (alarm/message)” is to be set for
the actuator type “Control (VdS)” and a monitoring current of 0 mA is to be set for controlling
the extinguishing zone.
The message “Fault, extinguishing system” must be programmed as a message with the ap-
propriate text LB1 to LBx.
9.1.2 Preaction sprinkler extinguishing control module
With standard extinguishing interface (SST).
Activation of preaction sprinkler systems via SIGMASYS systems.
Alarm valve activation:
The systems are preferably to be activated by addressing an automatic detector in the fire
alarm control and indicating panel. The fire detectors can be linked in two-detector or two-
zone dependency in order to avoid inadvertent tripping.
Activation criteria of the reversing electromagnetic valve:
Fault on the tripping detector zone
Disablement of the tripping detector zone
Partial fault on the monitored line relating to the extinguishing command
Fault on the monitored control line of the tripping command
Disablement of the monitored control line of the tripping command
Fault in one of the extinguishing zones relating to central processing nodes in the fire
alarm control and
indicating panel
Multifunctional Danger Control and Indicating Panels SIGMASYS C and M (M-Modules) 57 / 128
Best.Nr. A24205-A337-B970 – Edition 12 (03/07)
