Siemens SIMATIC ET200SP PS 6EP7133-6AB00-0BN0 24 V/5 A User Manual

Description, device design, dimension drawing
2.4 Status displays and signaling
SIMATIC ET200SP PS
12 Manual, 03.2018, A5E43207434
2.4
Status displays and signaling
6EP7133-6AB00-0BN0 (24 /5 A)
6EP7133-6AE00-0BN0 (24 V/10 A)
Status display
LED green for 24 V O.K.
Signaling contact (13,14)
Contact rating (isolated): 30 V AC/0.5 A, 60 V DC/0.3 A, 30 V DC/1 A) for 24 V O.K.
Current monitoring terminals
Voltage proportional to the output current: ~ 1 V ≙ I
out rated
±50 mV
Table 2- 1 I
Monitor
conversion table
6EP7133-6AB00-0BN0 (24 V/5 A)
6EP7133-6AE00-0BN0 (24 V/10 A)
Output current
[A]
I
Monitor
[V]
Output current
[A]
I
Monitor
[V]
0.0
0.0
0.0
0.0
0.5
0.1
1.0
0.1
1.0
0.2
2.0
0.2
1.5
0.3
3.0
0.3
2.0
0.4
4.0
0.4
2.5
0.5
5.0
0.5
3.0
0.6
6.0
0.6
3.5
0.7
7.0
0.7
4.0
0.8
8.0
0.8
4.5
0.9
9.0
0.9
5.0
1.0
10
1.0
Figure 2-4 Operating displays and signaling

Siemens SIMATIC ET200SP PS 6EP7133-6AB00-0BN0 24 V/5 A Specifications

General

Input Voltage	24 V DC
Output Voltage	24 V DC
Output Current	5 A
Mounting Type	DIN Rail
Category	Power Supply
Power Rating	120 W
Protection Class	IP20
Storage Temperature	-40 to +85 °C
Product Type Designation	6EP7133-6AB00-0BN0
Operating Temperature	-20 to +60 °C
Relative Humidity	5% to 95%, non-condensing
Standards	UL
