Description, device design, dimension drawing
2.6 Dimensions and weight
SIMATIC ET200SP PS
Manual, 03.2018, A5E43207434
15
2.6
Dimensions and weight
Figure 2-6 Dimensions and weight
6EP7133-6AB00-BN0 (24 V/5 A)
6EP7133-6AE00-0BN0 (24 V/10 A)
Dimensions (W × H × D) in mm
160 × 117 × 66.5
160 × 117 × 66.5
Weight
Approx. 0.5 kg
Approx. 0.72 kg

Table of Contents

Questions and Answers:

Question and Answer IconNeed help?

Do you have a question about the Siemens SIMATIC ET200SP PS 6EP7133-6AB00-0BN0 24 V/5 A and is the answer not in the manual?

Siemens SIMATIC ET200SP PS 6EP7133-6AB00-0BN0 24 V/5 A Specifications

General IconGeneral
Input Voltage24 V DC
Output Voltage24 V DC
Output Current5 A
Mounting TypeDIN Rail
CategoryPower Supply
Power Rating120 W
Protection ClassIP20
Storage Temperature-40 to +85 °C
Product Type Designation6EP7133-6AB00-0BN0
Operating Temperature-20 to +60 °C
Relative Humidity5% to 95%, non-condensing
StandardsUL
