Siemens SIMATIC ET200SP PS 6EP7133-6AB00-0BN0 24 V/5 A User Manual

SIMATIC ET200SP PS
Manual, 03.2018, A5E43207434
27
Technical data
6
Note
Technical data apply for a rated input voltage, rated load and 25
°C ambient temperature if
nothing else is specified.
6.1
Input
6EP7133-6AB00-0BN0 (24 V/5 A)
6EP7133-6AE00-0BN0 (24 V/10 A)
Input
1-phase, AC
1-phase, AC
Rated voltage U
in rated
120 - 230 V
120 - 230 V
Voltage range
• Comment
85 - 132/170 - 264 V
Derating at ≤ 60 °C:
85 V AC and 170 V AC: 90 % P
out rated
≥ 100 V AC and ≥ 200 V AC: 100 % P
out rated
between 85 V AC and 100 V AC, 170 V AC and 200 V AC linear interpolation
automatic range switchover
Yes
Yes
Connect/shutdown threshold, typical 68 V/59 V or
140 V/135 V
67 V/61 V or
142 V/137 V
Line supply buffering at I
out rated
, min
20 ms
20 ms
Power-failure buffering
at 93/187 V
at 93/187 V
Rated line frequency
50 - 60 Hz
50 - 60 Hz
Line frequency range
47 - 63 Hz
47 - 63 Hz
Input current at rated input voltage
120 V
2.1 A 4.3 A
Input current at rated input voltage
230 V
1.2 A 1.9 A
Inrush current limiting (25 °C), max.
45 A
60 A
I
2
t, at AC 120 V, max.
1 A
2
s
5.6 A
2
s
I
2
t, at AC 230 V, max.
3.15 A
2
s
6.3 A
2
s
Integrated input fuse
Fuse T 3.15 A
Fuse T 6 A
Protection in the line feeder cable
(IEC 898)
Recommended: Miniature circuit
breaker, characteristic B, 6 A or C, 3 A
Recommended: Miniature circuit
breaker, characteristic B, 10 A or C, 6 A

Siemens SIMATIC ET200SP PS 6EP7133-6AB00-0BN0 24 V/5 A Specifications

General

Input Voltage	24 V DC
Output Voltage	24 V DC
Output Current	5 A
Mounting Type	DIN Rail
Category	Power Supply
Power Rating	120 W
Protection Class	IP20
Storage Temperature	-40 to +85 °C
Product Type Designation	6EP7133-6AB00-0BN0
Operating Temperature	-20 to +60 °C
Relative Humidity	5% to 95%, non-condensing
Standards	UL
