SIMATIC ET200SP PS
Manual, 03.2018, A5E43207434
17
Mounting/removal
3
WARNING
Installing the device in a housing or a control cabinet
SIMATIC ET200SP PS power supplies are built-in devices. They must be installed in a
housing or control cabinet where only qualified personnel have access.
The device can be mounted in a control cabinet on standard mounting rails (see Chapter
Mechanical system (Page 34))
Mounting
To mount the device, position it with the mounting rail guide at the upper edge of the
standard mounting rail and press down to lock it into place. If it is difficult to snap the device
into place, press the button at the same time, as described under "Removal".
Removal
To remove, press button ⑧ (see Removal diagram (Page 17)) by hand downwards – and
withdraw the device at the lower edge of the standard mounting rail. Then you can remove
the device from the upper edge of the standard mounting rail.
Figure 3-1 Removal

Siemens SIMATIC ET200SP PS 6EP7133-6AB00-0BN0 24 V/5 A Specifications

General

Input Voltage	24 V DC
Output Voltage	24 V DC
Output Current	5 A
Mounting Type	DIN Rail
Category	Power Supply
Power Rating	120 W
Protection Class	IP20
Storage Temperature	-40 to +85 °C
Product Type Designation	6EP7133-6AB00-0BN0
Operating Temperature	-20 to +60 °C
Relative Humidity	5% to 95%, non-condensing
Standards	UL
