Technical data
6.3 Efficiency
SIMATIC ET200SP PS
32 Manual, 03.2018, A5E43207434
6.3
Efficiency
6EP7133-6AB00-0BN0 (24 V/5 A)
6EP7133-6AE00-0BN0 (24 V/10 A)
Efficiency at U
out rated
, I
out rated
120 V/230 V AC approx.
87 %/88 % 89.5 %/90 %
Power loss at U
out rated
, I
out rated
120 V/230 V AC approx.
17 W/15 W 27 W/26 W
Power loss when idling
120 V/230 V AC approx.
3 W/2.7 W 3.2 W/2.8 W
Figure 6-5 Efficiency, 6EP7133-6AB00-0BN0
Figure 6-6 Efficiency, 6EP7133-6AE00-0BN0

Siemens SIMATIC ET200SP PS 6EP7133-6AB00-0BN0 24 V/5 A Specifications

General

Input Voltage	24 V DC
Output Voltage	24 V DC
Output Current	5 A
Mounting Type	DIN Rail
Category	Power Supply
Power Rating	120 W
Protection Class	IP20
Storage Temperature	-40 to +85 °C
Product Type Designation	6EP7133-6AB00-0BN0
Operating Temperature	-20 to +60 °C
Relative Humidity	5% to 95%, non-condensing
Standards	UL
