Safety, approvals, EMC
7.3 Approvals
SIMATIC ET200SP PS
Manual, 03.2018, A5E43207434
37
7.3
Approvals
6EP7133-6AB00-0BN0 (24 V/5 A)
6EP7133-6AE00-0BN0 (24 V/10 A)
CE marking
yes, (2014/35/EU, 2014/30/EU and 2011/65/EU)
CSA approval
yes, CSA C22.2 No. 60950-1, being prepared
UL/cUL approval
cULus-listed (UL 508, CSA 22.2 No. 107.1), File E197259
Explosion protection
UL/cUL: ANSI/ISA-12.12.01-2015 Class I, Div. 2, Group ABCD, T4
CB approval
Yes
CB-Scheme
IEC 60950-1
7.4
EMC
6EP7133-6AB00-0BN0 (24 V/5 A)
6EP7133-6AE00-0BN0 (24 V/10 A)
Electrostatic discharge
EN 61000-4-2
8 kV contact, 8 kV air
Electromagnetic fields
EN 61000-4-3
2400 - 2700 MHz 10 V/m
Fast transient disturbance
variables (burst)
EN 61000-4-4 4 kV at line connections
2 kV at DC output
Surge voltages EN 61000-4-5 2 kV symmetrical at the line connections
4 kV asymmetrical at the line connections
500 V symmetrical/asymmetrical on DC output cables
High-frequency fields
EN 61000-4-6
10 V; 0.15 - 80 MHz
Magnetic fields
EN 61000-4-8
30 A/m; 50 Hz
Voltage dips EN 61000-4-11 100% for 20 ms,
60% for 200 ms,
30% for 500 ms
Voltage interruptions
EN 61000-4-11
100% for 5000 ms
Emitted interference
EN 55022
Class B
Line harmonics limitation
EN 61000-3-2
Class A
Generic standards
EN 61000-6-2
Immunity for industrial environments
EN 61000-6-3
Emission for residential areas
