Technical data
6.4 Closed-loop control
SIMATIC ET200SP PS
Manual, 03.2018, A5E43207434
33
6.4
Closed-loop control
6EP7133-6AB00-0BN0 (24 V/5 A)
6EP7133-6AE00-0BN0 (24 V/10 A)
Dyn. line regulation
(U
in rated
±15 %), max.
0.3 % 0.3 %
Dyn. load regulation
(I
out
: 10/90/10 %), U
out
± max.
5 % 5 %
Dyn. load regulation
(I
out
: 10/90/10 %), U
out
± typ.
3 % 3 %
Load-step settling time
10 to 90 %, max.
1 ms 1 ms
Load-step settling time
10 to 90 %, typ.
1 ms 1 ms
Load-step settling time
90 to 10 %, max.
1 ms 1 ms
Load-step settling time
90 to 10 %, typ.
1 ms 1 ms
6.5
Protection and monitoring
6EP7133-6AB00-0BN0 (24 V/5 A)
6EP7133-6AE00-0BN0 (24 V/10 A)
Output overvoltage protection
in the case of an internal fault U
out
< 31.8 V
in the case of an internal fault U
out
< 31.8 V
Current limitation, typ.
• Remark
7.5 A
Overload capability with
150 % I
out rated
up to 5 s/min
15 A
Overload capability with
150 % I
out rated
up to 5 s/min
Short-circuit protection
Yes, current is statically limited
Yes, current is statically limited
Continuous short-circuit
current rms value, approx.
7 A 14.1 A
6.6
MTBF
6EP7133-6AB00-0BN0 (24 V/5 A)
6EP7133-6AE00-0BN0 (24 V/10 A)
Mean Time Between Failures SN29500:
> 1000000 h
at 40 °C, rated load, 24 h operation

Siemens SIMATIC ET200SP PS 6EP7133-6AB00-0BN0 24 V/5 A Specifications

General

Input Voltage	24 V DC
Output Voltage	24 V DC
Output Current	5 A
Mounting Type	DIN Rail
Category	Power Supply
Power Rating	120 W
Protection Class	IP20
Storage Temperature	-40 to +85 °C
Product Type Designation	6EP7133-6AB00-0BN0
Operating Temperature	-20 to +60 °C
Relative Humidity	5% to 95%, non-condensing
Standards	UL
