Siemens SIMATIC ET200SP PS 6EP7133-6AB00-0BN0 24 V/5 A User Manual

SIMATIC ET200SP PS
Manual, 03.2018, A5E43207434
35
Safety, approvals, EMC
7
7.1
Safety
6EP7133-6AB00-0BN0 (24 V/5 A)
6EP7133-6AE00-0BN0 (24 V/10 A)
Primary/secondary galvanic isolation
Yes
Galvanic isolation SELV output voltage U
out
acc. to EN 60950-1
Transformer according to EN 61558-2-16
Protection class
Class I
Degree of protection (EN 60529) IP20
Leakage current, typ.
1 mA
Leakage current, max.
3.5 mA
Test voltage See Table 7-1 Test voltage for 6EP7133-6AB00-0BN0 and
6EP7133-6AE00-0BN0 (Page 36)

Siemens SIMATIC ET200SP PS 6EP7133-6AB00-0BN0 24 V/5 A Specifications

General

Input Voltage	24 V DC
Output Voltage	24 V DC
Output Current	5 A
Mounting Type	DIN Rail
Category	Power Supply
Power Rating	120 W
Protection Class	IP20
Storage Temperature	-40 to +85 °C
Product Type Designation	6EP7133-6AB00-0BN0
Operating Temperature	-20 to +60 °C
Relative Humidity	5% to 95%, non-condensing
Standards	UL

Summary

Overview of SIMATIC ET200SP PS Power Supply

Device Description

Overview of the SIMATIC ET200SP PS power supply's features and capabilities.

Connections and Terminal Designation

Potentiometer Adjustment

Safety Instructions

General Safety Instructions

Provides guidance on the safe handling and operation of the device.

Safety Instructions for Hazardous Zones

Specific safety precautions for operating the device in hazardous areas.

Mounting and Removal

Mounting Procedure

Instructions for securely mounting the power supply onto a standard mounting rail.

Removal Procedure

Mounting Position and Clearances

Standard Mounting Position

Details the correct vertical mounting orientation and required clearances for optimal performance.

Installation

Line-Side Connection

Instructions for connecting the power supply to the AC mains supply.

Output-Side Connection

Guidance on connecting the DC output terminals to loads and proper grounding.

Technical Data

Input Specifications

Output Specifications

Detailed specifications for the DC output voltage, current, and performance characteristics.

Protection and Monitoring

Safety, Approvals, and EMC

Safety Information

Information on galvanic isolation, protection class, and leakage currents.

Applications

Parallel Connection for Power Rating

Series Connection for Increased Voltage

Output Overload Protection

Protection Against Longer Power Failures

Service and Support

Technical Support Channels

Contact information and channels for obtaining technical assistance from Siemens.
