4-5
TP27, TP37 Equipment Manual
Release 01/00
Functions are called in on the T
ouch Panel by means of configured buttons. T
o
prevent unauthorized access, some functions have to be protected beforehand
by means of a password at a specific password level (see chapter 5).
Configured help texts can be called int the standard screens by
pressing the button shown here.
HELP
Calling functions
Calling Help texts
Screens
41
43
Table of Contents
Default Chapter
8
Table of Contents
8
Release
13
Release
14
1 Product Description
16
Visualizing and Controlling Processes
16
The Touch Panels at a Glance
18
2 Functionality
20
Part II FUNCTIONS of the TOUCH PANELS
24
3 General Operation
26
Operating Touch Elements
29
Entering Values
31
Entering Numerical Values
31
Entering Alphanumeric Values
33
Entering Symbolic Values
35
Help Text
36
4 Screens
38
Screen Elements
38
Standard Screens
40
5 Password Protection
44
Password Level and Access Permissions
44
Login/Logout on the Touch Panel
46
Password Management
48
6 Messages
52
Types of Message
53
Event Messages and Alarm Messages
53
Alarm Messages
57
System Messages
59
Displaying Messages
60
Opening a Message Page
62
Opening a Message Buffer
64
Deleting Messages
65
Printing Messages
67
ALARM_S Messages
69
Communication Sequence
70
Message Acknowledgement
71
Printing Messages
71
Message Overload
72
Updating
73
Buffer Overflow
74
Standard Screens for Messages
75
Edit Message" Standard Screen
75
Output Messages" Standard Screen
77
System Settings" Standard Screen
79
7 Printing
82
8 Recipes
86
Standard Screens for Recipes
88
Creating, Editing and Saving Data Records
93
Transferring Data Records
98
Record Sets
100
9 Storing and Loading Data
104
Data Types, Data Media and Storage Principle
104
Delete Storage Medium
106
Backup/Restore
108
10 Status/Force Variable Using the TP
112
Status Variable
113
Force Variable
116
11 System Settings
118
Setting an Operating Mode
121
Blanking the Screen
122
Deactivate Touch Screen
123
Calibrating the Touch Screen (TP37 and TP27-10 Only)
124
Other Settings
125
Part III INSTALLATION and COMMISSIONING
128
12 Installation
130
Mechanical Installation
131
Electrical Installation
135
Power Supply and Relay Contacts
137
Connecting the Configuration Computer
138
Connecting the PLC
139
Connecting a Printer
141
13 Commissioning
142
Initial Startup
144
Recommissioning
145
Startup Behavior
149
Testing a Configuration in OFFLINE Mode
150
Testing the Configuration in Conjunction with the PLC
151
14 Unit Description TP27-6
154
Dimensions
154
Operating Elements
155
Connection Elements
155
Communication Options
156
15 Unit Description TP27-10
158
Dimensions
159
Operating Elements
160
Connection Elements
160
16 Unit Description TP37
162
Dimensions
163
Operating and Display Elements
164
Connection Elements
166
Communication Options
167
17 Options
168
Installing the Direct Key Module
169
Connectors and Adjusters
171
Control Panel Interface
173
Installing the Control Panel Interface
174
Connectors
176
18 Maintenance/Upkeep
178
Cleaning the Screen
178
Replacing the Backup Battery
179
Replacing the Back-Lighting (TP37 Only)
181
Part V APPENDICES
184
A Technical Data
184
Direct Key Module and Control Panel Interface
190
Chemical Resistance of the Touch Panel
193
Interface Assignments
196
System Messages
200
Index
205
