Maintaining and repairing the device
6.3 Installing and removing hardware
SIMATIC IPC227E
68 Operating Instructions, 11/2016, A5E35782395-AB
Replacing the drive of a basic device
The procedure only applies to the basic device: Carry out the procedure if you want to
replace the hard disk drive with an SSD and vice versa or in the case of a fault.
Read the information in section "Repair information (Page 63)".
● The device is open.
● A hard disk drive or an SSD
● A T10 screwdriver
Pull out the connection plug.
Lay down the device's rear panel
including the drive.
Remove the indicated screws.
Remove the drive rack and take
out the SSD.
