Installing and connecting the device
3.1 Preparing for installation
SIMATIC IPC527G
20 Operating Instructions, 03/2019, A5E45491226-AA
Permitted mounting positions
Points to note with expansion cards
Expansion cards may impose restrictions on the installation location (fire-proof enclosure)
and permitted mounting positions (see General technical specifications (Page 62)). If the
device has been fitted with expansion cards, please observe the safety and installation
instructions for the expansion cards in the corresponding documentation.
If in doubt, install the device in an enclosure that is compliant with IEC/UL/EN/DIN-EN
60950-1, sections 4.6 and 4.7.3.
Note
The device is approved
for indoor operation only.
Ensure that the required minimum clearance of 100 mm to the area of the ventilation slots.
The following mounting positions are permitted:
