Technical specifications
7.5 Hardware descriptions
SIMATIC IPC527G
Operating Instructions, 03/2019, A5E45491226-AA
67
7.5
Hardware descriptions
7.5.1
Technical features of the motherboard
Component /
port
Description
Parameters
Chipset
Intel® H110
Intel® H110
CPU Intel Processor
• Intel® Pentium® Processor G4400 (3M Cache, 3.30 GHz)
• Intel® Core™ i5-6500 Processor (6M Cache, up to
3.60 GHz)
• Intel® Core™ i7-6700 Processor (8M Cache, up to
4.00 GHz)
Memory DDR4 SDRAM Memory expansion up to 32 GB with the following memory
modules (without ECC):
• 4G DDR4 SDRAM
• 8G DDR4 SDRAM
• 16G DDR4 SDRAM
Graphics
Integrated graphics
up to 512 MB graphics memory taken dynamically from RAM
7.5.2
External interfaces
7.5.2.1
Overview of interfaces
Interface
Position
Description
COM External 9-pin D-sub:
• 2 × RS 232
• 2 × RS 232/ RS 422/ RS 485
USB
1
External
• 4 × USB 3.0
• 2 × USB 2.0 (optional)
Ethernet External 2 × 10/100/1000 Mbps (two RJ45),
3 × 10/100/1000 Mbps (three RJ45) optional
DisplayPort External
• 1 × DP
• 1 × VGA
DIO (Digital Input Output) External DB9 connector
Digital Input (5V TTL) and Output (5V 12mA)
1
Only four of these USB ports may be operated simultaneously in high current mode, max. 10 W.
