Technical information
8.4 Technical specifications
SIMATIC IPC677D
124 Operating Instructions, 09/2014, A5E32995420-AC
Connection of DVI display devices
Connection of DisplayPort display devices
USB 4 × USB 3.0, a maximum of 2 can be operated in high-current mode
at the same time
Front USB 3.0 for device with resistive single touch
PROFIBUS / MPI interface,
isolated
- Transmission speed
9-pin Cannon socket, 2-row
9.6 kbps to 12 Mbps
DP master: DP-V0, DP-V1 with SOFTNET-DP
DP slave: DP-V0, DP-V1 with SOFTNET-DP slave
PROFINET
3
RJ45 connector, CP1616 compatible, on-board interface on ERTEC
400 basis, 10/100 Mbps electrically isolated
Ethernet
3
2 × Ethernet port (RJ45) Intel WGI217LM and
Intel WGI210IT10/100/1000 Mbps, electrically isolated
Wake on LAN, Remote Boot, teaming and Jumboframes up to 9014
4 5
RS232, 115 kbps max., 9-pin SUB-D, male
Free slots for expansion
2 PCI/PCIe cards
For unique labeling, the Ethernet ports are numbered on the enclosure. The numbering by the
operating system can differ.
No teaming with AMT.
5
When using AMT, the interface x1 p1 must be used for connection to remote maintenance.
