Commissioning the device
4.2 Switching on the device
SIMATIC IPC677D
50 Operating Instructions, 09/2014, A5E32995420-AC
Following the initial startup, the operating system preinstalled on the drive is automatically
configured on the device.
If you change the default values in the BIOS Setup or if you turn off the device during
installation, you disrupt the installation and the operating system is not installed correctly.
The operating safety of the device and the plant is at risk.
Do not switch off the device during the entire installation process. Do not change the default
values in the BIOS Setup.
1. Set the On/Off switch to "ON" position.
The "PC ON/WD" LED lights up. The module carries out a self-test. During the self-test,
the following message appears:
Press Esc for Boot Options
2. Wait for the message to disappear.
3. Follow the instructions on the screen.
The following steps are only to be performed for initial startup of the device with factory
settings:
4. Make the region and language settings.
If you want your system language to be international, select English. Information about
changing the region and language settings is available in the section "Servicing and
maintaining the device", under "Installing software".
Note
Once the operating system has been set up, the device may restart.
5. Type in the product key as required.
You can find the product key among the identification data of the device on the
"Certificate of Authenticity" COA label, in the "Product Key" line.
6. If the device is delivered with pre-installed software, the setup of the SIMATIC IPC Wizard
is started automatically after operating system installation (see the following section).
The installation of the operating system is complete.
