Siemens SIMOTICS S-1FT7 User Manual

Technical data and characteristic curves
6.3 Data sheets and characteristics
S-1FT7 synchronous motors
232 Configuration Manual, 09/2018, A5E45099423B AA
6.3.2
1FT7 Compact - forced ventilation
6.3.2.1
1FT7084-_S
Three-phase servomotor 1FT7084 - 5SC7
Technical specifications
Symbol
Unit
Value
Configuration data:
Rated speed
n
N
rpm
2000
Rated torque (100K)
M
N(100K)
Nm
24
Rated current (100K)
I
N(100K)
A
13.5
Static torque (100K)
M
0(100K)
Nm
27
Stall current (100K)
I
0(100K)
A
15
Static torque (60K)
M
0(60K)
Nm
21.5
Stall current (60K)
I
0(60K)
A
12
Optimum operating point
Optimum speed
n
opt
rpm
2000
Optimum power
P
opt
kW
5.0
Limiting data:
Max. permissible speed (mech.)
n
max mech
rpm
8000
Maximum torque M
max
Nm 81
Maximum current
I
max
A
55
Motor data:
No. of poles
2p
10
Torque constant (100K)
k
T
Nm/A
1.8
Voltage constant (at 20 °C)
k
E
V/1000 rpm
115
Winding resistance (at 20 °C)
R
Str
W
0.345
Rotating field inductance
L
D
mH
5.4
Electrical time constant
T
el
ms
16
Mechanical time constant
T
mech
ms
1.4
Thermal time constant
T
th
min
35
Moment of inertia
J
mot
kgm
2 ,
10
-4
45
Shaft torsional stiffness
c
t
Nm/rad
88000
Weight
m
mot
kg
25
Motor data with integrated brake:
Moment of inertia (with brake)
J
mot
kgm
2 ,
10
-4
60
Shaft torsional stiffness (with brake)
c
t
Nm/rad
65000
Weight (with brake)
m
Mot
kg
29
Data with SINAMICS S120 Booksize / S120 Booksize Compact
Rated converter current I
N Inv
A 18
Maximum converter current
I
max Inv
A
54
Max. torque (converter operation)
M
max Inv
Nm
80
Max. permissible speed (converter operation)
n
max Inv
rpm
5000
The rated data are valid for a 600 V DC-link voltage
