Siemens SIMOTICS S-1FT7 User Manual

Motor components and options
4.1 Motor components
S-1FT7 synchronous motors
Configuration Manual, 09/2018, A5E45099423B AA
69
The temperature sensor is part of an SELV circuit, which can be destroyed if a high voltage
is applied. The temperature sensor is designed so that the DIN/EN requirement for
"protective separation" is fulfilled.
Due to the thermal coupling time of the temperature sensor, high short-term overloads
require additional protective measures.
NOTICE
Destruction of the motor for a thermal critical load
A thermal critical load, e.g. high overload at motor standstill, can destroy the motor.
• Use an overcurrent relay, for example, as an additional protective measure.
4.1.2
Encoders
4.1.2.1
Encoders for 1FT7 motors
NOTICE
Destruction of the encoder when incorrectly handling ESD parts and components
Encoders are ESD components.
• Comply with the regulations for handling parts and components that can be destroyed
by electrostatic discharge, see Equipment damage due to electric fields or electrostatic
discharge (Page 16).
The following encoders can be used with the 1FT7.
Encoders with DRIVE-CLiQ interface:
For SINAMICS drive systems
Incremental encoders or singleturn encod-
ers
Multiturn absolute encoders
High resolution, suitable for Safety Integrated Extended Functions
Encoder designation
AS24DQI
AM24DQI
Identification in the article num-
ber
B, K
2) 3)
C, L
2)
Resolution
16,777,216 = 24 bits
16,777,216 = 24 bits
Absolute position
Yes, one revolution
Yes, 4096 revolutions (12 bits)
Max. angular error
± 40"
± 40"
Average resolution, suitable for Safety Integrated Extended Functions
Encoder designation
IC22DQ
1)
AM22DQ
1)
Identification in the
article number
D
3) 4)
F
3) 4)
