Page #140 background imageLoading...
Page #140 background image
Spare parts
10.9 Ordering example
1LA5/6/7/9, 1LG4/6, 1MA6/7, 1MB..1/2/3/4/5 - SH 63 ... 355
138 Operating Instructions, 06/2018, A5E44455710A
The following supply commitments apply to replacement machines and repair parts following
delivery of the motor:
For up to 3 years after the delivery of the original machine, in the event of total machine
failure, Siemens will supply a comparable replacement machine with regard to the
mounting dimensions and functions; it is possible that this will involve a new series.
If a replacement machine is supplied within the 3 year period, this does not mean that the
warranty restarts.
Replacement machines delivered after the active production of the machine series are
also identified as spare motors on the rating plate.
Spare parts are offered only for these spare motors on request; repair and replacement
are not possible.
After a period of 3 years (after the delivery of the original machine), it is only possible to
repair these machines (depending on the availability of the spare parts required).
For up to 5 years after the delivery of the original motor, spare parts will be available and
for a further 5 years, Siemens will provide information about spare parts and will supply
documents when required.
10.9
Ordering example
Table 10- 1 Ordering example
End shield, drive end
1.40 End shield
Machine type *
1MB1543-2BB03-4AA4
Ident: No. * UC 1706/218923701
* corresponding to the rating plate
Take the type and serial number from the rating plate and the machine documentation.
When replacing rolling-contact bearings, in addition to the bearing identification code, the
replacement code for the bearing version is required. Both of these codes are specified on
the rating plate and in the machine documentation. They are also shown on the installed
bearings.
The graphical representations in this chapter show schematic diagrams of the basic
versions. They are used for spare part definitions. The supplied version may differ in details
from these representations.
