Siemens SIMOTICS XP 1MB1 series User Manual

Electrical connection
6.6 Conductor connection
1LA5/6/7/9, 1LG4/6, 1MA6/7, 1MB..1/2/3/4/5 - SH 63 ... 355
80 Operating Instructions, 06/2018, A5E44455710A
6.6
Conductor connection
Cross-sections that can be connected depending on the size of the terminal (possibly
reduced due to size of cable entries)
Table 6- 4 Max. conductor connection for standard machines and Ex tc
Shaft height
Max. connectable conductor cross-section
mm²
63 ... 90 1.5
2.5 with cable lug
100 ... 112
4.0
132
6.0
160 ... 180
16.0
200
25.0
225
35.0 with cable lug
250 ... 280
120.0
315
240.0
Table 6- 5 Max. conductor connection for explosion-protected machines (with the exception of Ex
tc) and VIK in the standard version
Shaft height
Max. connectable conductor cross-section
mm²
63 ... 112
4.0
132
6.0
160
16.0
180
10.0
180 (1LG4, 1LG6)
16.0
200 ... 225
50.0
250 ... 280
120.0
315
240.0
