Spare parts
10.10 Machine parts
1LA5/6/7/9, 1LG4/6, 1MA6/7, 1MB..1/2/3/4/5 - SH 63 ... 355
Operating Instructions, 06/2018, A5E44455710A
139
10.10
Machine parts
10.10.1
Part lists
Part
Description
Part
Description
1.00
DE bearings
Terminal box, complete
1.30 Bolt 5.37 Spring lock washer
1.31
Spring lock washer
5.42
Terminal box housing, including seal
1.32
Bolt
5.43
Entry plate
1.33
Nut
5.44
Terminal box upper section
1.40
End shield
5.45
Enclosure
1.43
Shaft sealing ring
5.46
Screw
1.44
Bearing cover DE, inner
5.47
Screw
1.45
Screw (bearing cover)
5.48
Spring lock washer
1.46
Cover ring
5.49
Screw
1.47
O ring
5.51
Flanged nut
1.48
Bolt
5.52
Cable entry
1.49
Bolt
5.53
Screw plugs
1.50
Flanged nut
5.54
O ring
1.56
Spacer washer
5.55
Nut
1.58
Spring washer
5.60
Screw
1.60
Roller bearing
5.61
Screw
1.61
Spring band for end shield hub
5.62
Spring lock washer
1.63
Condensation drain plug
5.63
Mounting rail
1.65
Grease nipple
5.64
Spring lock washer
1.67 Bearing cover NDE, outer 5.65 Bolt
1.68
Grease slinger (optional)
5.68
Screw plugs
1.69
Compression spring
5.69
O ring
3.00
Rotor, complete
5.70
Terminal clamp
3.02
Locking ring
5.72
Contact bracket
3.03
Locking ring
5.76
Terminal plate / contact bracket
3.38
Featherkey
5.78
Spring lock washer
3.88
Featherkey for fan
5.79
Screw
4.00
Stator, complete
5.81
Screw
4.04
Eyebolt
5.82
O ring
4.05
Disk
5.83
Seal
4.07
Housing foot
5.84
Terminal box cover
4.08
Housing foot, left
5.85
Terminal box cover including seal (optional screw)
4.09
Housing foot, right
5.88
Spring lock washer
4.10
Spring lock washer
5.89
Screw
4.11 Bolt 5.90 Upper terminal box section can be rotated 4 x 90 de-
grees, complete
(for subsequent mounting)
