Technical specifications and drawings
B
Note
Finding technical data and drawings
The technical data and the necessary drawings can be found in "Technical data and drawings"
manual.
B.1 Standards and regulations
Table B-1 Standards and regulations
Directives
Standards DIN EN 61800‑3/VDE 0160 Part 103 (IEC 61800-3)
DIN EN 61800‑4 / VDE 0160 T104 (IEC 61800-4); only to the extent that it can
be applied
DIN EN 61800‑5‑1/VDE 0160 Part 105 (IEC 61800-5-1)
DIN EN 60146‑1‑1 / VDE 0558 T11 (IEC 60146-1-1); only to the extent that it can
be applied
DIN EN 60204‑11 / VDE 0113 T11 (IEC 60204-11); only to the extent that it can
be applied
EU directives Machinery Directive:
2006/42/EC + amendments
Electromagnetic compatibility:
2014/30/EU + amendments
CE marking According to Low Voltage Direction (only applies to the low-voltage parts, e.g.
the control cabinet
2014/35/EU + amendments
Protection class Class 1 in accordance with DIN EN 61140/VDE 0140 Part 1 (IEC 61140)
Touch protection BGV A3
Insulation According to DIN EN 61800‑5‑1 / VDE 0160 T105 (IEC 61800-5-1): Pollution
degree 2 (without conductive pollution), non-condensing
Radio interference
level
According to DIN EN 61800-3/VDE 0160 Part 100 (IEC 61800-3): no RI sup‐
pression
Environmental condi‐
tions
DIN EN 60721-3-1/2/3 (IEC 60721-3-1/2/3)
SINAMICS SL150 6SL38600UL432AA0Z
Operating Instructions Rev.201910281433 EXAMPLE 109
