4.4 Transportation
The terms are defined as follows in the following part of the instructions:
● "Transportation unit" refers to the unit before it has been unpacked
● "Cabinet" refers to the unit after it has been unpacked
4.4.1 Transport markings
The packing differs depending on the transport type and size. If not otherwise contractually
agreed, the packaging corresponds to the packing guidelines for International Standards for
Phytosanitary Measures (ISPM).
Note the symbols which appear on the packing. These have the following meanings:
Top Fragile material Keep dry Keep cool Center of
gravity
Do not use
hand hook
Attach here
4.4.2 Transport requirements
● Persons driving cranes and fork-lift trucks must hold appropriate licenses.
● You must observe the specifications to avoid transport damage to the enclosure and you
must maintain the permissible climatic conditions during operation in accordance with
IEC 60721-3-1/2/3. Please also observe the "Technical specifications" instructions.
● For lifting the device, always use certified and adequately dimensioned cable guiding and
spreading devices that are in absolutely perfect condition. The weight of the device is
stamped on the rating plate. Carefully check the cable guide and/or spreading devices
before using them.
● When lifting, refer to the information on the lifting plate or in "Technical data and drawings."
NOTICE
Vibrations
Significant vibration during transportation and shocks when setting down can damage the
equipment.
Avoid vibrations and shocks.
Preparations for use
4.4 Transportation
SINAMICS SL150 6SL38600UL432AA0Z
Operating Instructions Rev.201910281433 EXAMPLE 43
