In order not to damage open mounting parts (e.g. pipes and busbars), take the following
measures when removing the foil and the load securing devices:
● Remove the foil and load securing devices carefully.
● Remove the packaging immediately prior to installation. Protect the cabinets against dust
until they have been commissioned. To do this, cover the ventilation openings and keep the
doors closed.
● Do not remove the safety instructions and center of gravity specifications from the cabinet.
4.5.2 Removing load securing devices
WARNING
Fixing materials can come under tensile stress
If fixing materials are released suddenly during opening and people get in the way, this could
result in bodily injury or death.
Release the retaining straps before opening. Stay out of the way of the impact direction of the
retaining straps.
NOTICE
Improper removal of the load securing devices
The load securing device protects the cabinet from any damage. If you remove the load
securing device improperly, the cabinet may sustain damage.
Correctly remove the load securing device.
To extract the load securing device, proceed as follows:
1. Remove the retaining straps.
2. Remove the spacers such as wooden wedges, air cushions, etc.
4.5.3 Lifting the cabinet off the transport pallet
Use a crane to lower the transportation units from the transport pallets and transport them to the
installation site. Observe the guidelines described in the section "Transport with a crane."
Preparations for use
4.5 Unpacking
SINAMICS SL150 6SL38600UL432AA0Z
Operating Instructions Rev.201910281433 EXAMPLE 49
