Scope of delivery PN Gate Dev Kit (Development Kit)
The PN Gate development kit is supplied on a DVD and contains the following components:
● STEP 7 add-on setup
– CD1
PN Gate add-on setup for STEP7 5.5 SP2, STARTER 4.3, SINAMICS 4.5
● PN Gate driver
– Bin
Binary files of the driver in the Tar format.
– Src
Source files as a zip file and unzipped.
– Doc
Doxygen documentation as zip file. The Doxygen documentation is available in HTML
and PDF format.
● Application example
– PROFIdrive sample applications in binary and in source code.
● Documentation
– German
PN Gate documentation in German.
– English
PN Gate documentation in English.
A.1.3.6 PROFINET with 2 controllers
Control Unit settings
Note
Operation with two controllers is only possible in conjunction with an F-CPU.
SINAMICS allows 2 control systems to be connected simultaneously to a Control Unit via
PROFINET, e.g. an automation controller (A-CPU) and a safety controller (F-CPU).
SINAMICS supports, for this communication, PROFIsafe standard telegrams 30 and 31, as
well as Siemens telegrams 901 and 902 for the safety controller.
Communication
A.1 Communication
Industrial Security
158 Configuration Manual, 08/2017, A5E36912609A
