Regis‐
ter
Description Ac‐
cess
Unit Scaling ON/OFF text
or Value range
Data / parameter
40514 Time constant D-component of the tech‐
nology controller
R/W - 1 0 … 60 p2274
40515 Max. limit of technology controller R/W % 100 -200.0 … 200.0 p2291
40516 Min. limit technology controller R/W % 100 -200.0 … 200.0 p2292
PID diagnostics
40520 Effective setpoint acc. to internal tech‐
nology controller MOP ramp-function
generator
R % 100 -100.0 … 100.0 r2250
40521 Actual value of technology controller af‐
ter filter
R % 100 -100.0 … 100.0 r2266
40522 Output signal technology controller R % 100 -100.0 … 100.0 r2294
1)
For these registers, for SINAMICS servo drives, parameters p1120 and p1121 are only available (and can only be
parameterized) with the extended setpoint channel.
2)
These registers are not supported for linear motors as the unit and value range differ from normal rotary drives.
3)
The technology controller parameters can only be accessed if, in the STARTER project, also the "Technology controller"
function module is activated.
Table A-16 Assignment of the Modbus register for general parameter access using DS47
Regis‐
ter
Description Ac‐
cess
Unit Scaling ON/OFF text
or Value range
Data / parameter
40601 DS47 Control R/W - - - -
40602 DS47 header R/W - - - -
40603 DS47 data 1 R/W - - - -
… …
40722 DS47 data 120 R/W - - - -
Note
Limited value range
Modbus TCP registers have a maximum 16 bit width. The values of display parameters (r
parameters) cannot always be represented with 16 bits. In these particular cases, the
maximum value that can be represented is displayed.
● Unsigned: 65535
● Signed min: -32768
● Signed max: 32767
A.1.4.5 Write and read access using function codes
Function codes used
For data exchange between the controller and device, predefined function codes are used for
communication via Modbus.
Communication
A.1 Communication
