5.6.7.2 Displaying faults and alarms
Pending alarms and faults from the drive are displayed. You can acknowledge the faults that
have not yet been acknowledged.
1. Click the "Messages and Logs" entry from the navigation.
2. Click the "Alarm display" tab. Current alarms and faults from the drive object are displayed.
Figure 5-18 Displaying alarm messages
The following information is displayed:
Column Explanation
Time Time of the event
Type Type of the event
Drive object Relevant drive object
Alarm Alarm ID with description
Component Number of the relevant component
The list of alarms and faults is updated automatically. You can limit the display to selected
entries of the "Type" and "Drive objekt" columns.
3. Acknowledge the faults. To do this, click the "Reset alarms" button. The faults are
acknowledged. The "Alarm display" tab is updated.
5.6.8 Displaying and changing drive parameters
5.6.8.1 Creating a parameter list
Access to all drive parameters is possible by means of user-defined parameter lists:
● Including DCC and Tec parameters
● Including Level 4 parameters if the corresponding password has been set
You can manage up to 20 parameter lists with up to 40 parameters each. The created
parameter lists are saved on the memory card of the drive. A parameter selection performed
once is retained for further access even after the drive is switched off.
Security measures for SINAMICS
5.6 Web server
Industrial Security
68 Configuration Manual, 08/2017, A5E36912609A
