57
Advanced Recording Operations
To fit optional microphones (operable with a 48 V supply)
other than the ECM-670
Use the same fitting procedure as for the ECM-670, but note the following differences
with respect to the microphone adaptor.
ECM-672: no microphone adaptor required.
Slender microphones (19 mm (3/4 inch) diameter): use the microphone adaptor
supplied with the CAC-12.
Note
When you use an external microphone, make sure that the wind screen does not appear
on the screen, using an underscan monitor.
When you unplug the microphone plug
Unplug it while pressing the PUSH button.
When using a microphone which is not powered through its cable
Connect the microphone to the AUDIO IN CH1/CH2 connector and set the LINE/MIC
selector to MIC.
Connecting an optional external microphone
