Sony Handycam HDR-FX1 User Manual

Using the Menu
64
REMAINING
DISP OUTPUT
b Note
• You cannot input a signal to your camcorder if you press DISPLAY/BATT INFO while
[V-OUT/PANEL] is selected.
REMOTE CTRL
b Note
• The setting returns to [ON] when you have the power source disconnected from your
camcorder for more than 5 minutes.
GAUTO Select to display the remaining tape indicator for about 8 seconds:
• After you set the POWER switch to CAMERA or VCR with a
cassette inserted, and your camcorder calculates the remaining
amount of tape.
• After you press N (play) or DISPLAY/BATT INFO.
ON Select to always display the remaining tape indicator.
GLCD PANEL Select to show indicators such as the time code on the LCD screen and
in the viewfinder.
V-OUT/PANEL Select to show indicators such as the time code on the TV screen, LCD
screen, and in the viewfinder.
GON Select when using the Remote Commander supplied with your
camcorder.
OFF Select to deactivate the Remote Commander to prevent your
camcorder from responding to a command sent by another VCR
remote control unit.

Sony Handycam HDR-FX1 Specifications

Imaging

imaging device	3- 1/3" 16:9 Advanced HAD™ CCD
pixel gross	1120K
video actual	1070K Pixels

Audio

dolby digital output	MPEG1 Audio Layer 2-Stereo (HDV), PCM (DV)
recording format	Stereo
microphone	Yes (Built-in)

Optics and Lens

35mm equivalent	32.5-390mm (Camera Mode), 40-480mm (4:3 TV Mode)
aperture	f1.6-f2.8
focal distance	4.5-54.0mm

Power

power consumption	7.4W/8.0W/8.4W (VF/LCD/VF LCD)
battery type	InfoLITHIUM® with AccuPower™ Meter System (NP-F570)
power requirements	7.2V (battery pack); 8.4V (AC Adaptor)

Weight and Dimensions

weight	4 lbs, 6.5 oz (2000g) main unit only; 4 lbs, 10 1/8 oz (2.1 kg) including the NP-F570 rechargeable battery pack, DVM60 cassette and lens hood
measurements	5 15/16" x 7 1/8" x 14 3/8" (151 x 181 x 365mm)
lcd	3.5" (250K Pixels Wide Precision Hybrid SwivelScreen™ LCD Display)
