Sony Handycam NEX-VG10 User Manual

51
GB
Table of
contents
Sample
images
Menu Index
Enlarge Still image
You can check the focus by enlarging a portion of the still image on the screen.
1 MENU button t [Playback] t [ Enlarge Still image].
2 Adjust the scaling by turning the control dial.
3 Select the portion you want to enlarge by pressing the v/V/b/B button.
4 To cancel the operation, press [Exit].
• You cannot enlarge the movies.
Note
z Scaling range
The scaling range depends on the image size.
Image size Scaling range
L Approx. ×1.1 – ×13
M Approx. ×1.1 – ×10
S Approx. ×1.1 – ×6.7

Sony Handycam NEX-VG10 Specifications

Optics and Lens

filter diameter	67 mm
focal length (photo)	27 mm-300 mm
focal length (video)	32.4 mm-360 mm
minimum focus distance	1 ft (wide end) - 1.6 ft (tele end)
angle of view	76°
maximum aperture (wide end)	F3.5
maximum aperture (tele end)	F6.3
minimum aperture (wide end)	F22
minimum aperture (tele end)	F40
lens weight	18.5 oz

LCD Display

lcd type	3.0" Xtra Fine LCD, 180° swivel
angle adjustment	Opening: 90°, Turning: 180°
brightness control	Manual (5 steps)

Imaging Sensor

effective picture resolution	14.2 megapixels
imaging sensor size	23.4 x 15.6 mm
pixel gross	14.6 megapixels

Power

battery type	Type V Battery
supplied battery	InfoLITHIUM NP-FV70
battery charger	AC-PW10AM

Weight and Dimensions

weight (body only)	620 g
weight (with battery, lens, and media)	1.3 kg
dimensions (W x H x D)	97 x 132 x 294 mm
