Sony Handycam NEX-VG10 User Manual

2
GB
Table of
contents
Sample
images
Menu Index
Notes on using the camcorder
How to use this handbook
Click on a button at upper right on the cover and each page to jump to the corresponding
page.
This is convenient when searching for a function you want to use.
You can jump to the pages by clicking on the page numbers mentioned in the book.
Search for information by
function.
Search for information by
sample images.
Search for information in
a listing of menu items.
Search for information by
keyword.
Marks and notations used in this handbook
In this handbook, the sequence of
operations is shown by arrows (t).
Operate the camcorder in the order
indicated.
The default setting is indicated by .
Indicates cautions and limitations
relevant to the correct operation of the
camcorder.
z Indicates information that is useful
to know.

Sony Handycam NEX-VG10 Specifications

Optics and Lens

filter diameter	67 mm
focal length (photo)	27 mm-300 mm
focal length (video)	32.4 mm-360 mm
minimum focus distance	1 ft (wide end) - 1.6 ft (tele end)
angle of view	76°
maximum aperture (wide end)	F3.5
maximum aperture (tele end)	F6.3
minimum aperture (wide end)	F22
minimum aperture (tele end)	F40
lens weight	18.5 oz

LCD Display

lcd type	3.0" Xtra Fine LCD, 180° swivel
angle adjustment	Opening: 90°, Turning: 180°
brightness control	Manual (5 steps)

Imaging Sensor

effective picture resolution	14.2 megapixels
imaging sensor size	23.4 x 15.6 mm
pixel gross	14.6 megapixels

Power

battery type	Type V Battery
supplied battery	InfoLITHIUM NP-FV70
battery charger	AC-PW10AM

Weight and Dimensions

weight (body only)	620 g
weight (with battery, lens, and media)	1.3 kg
dimensions (W x H x D)	97 x 132 x 294 mm
