Sony Handycam NEX-VG10 User Manual

53
GB
Table of
contents
Sample
images
Menu Index
Grid Line
Sets whether the grid line is displayed or not. The grid line will help you to adjust the
composition of images.
1 MENU button t [Setup] t [Grid Line] t desired setting.
On Displays the grid line.
Off Does not display the grid line.

Sony Handycam NEX-VG10 Specifications

Optics and Lens

filter diameter	67 mm
focal length (photo)	27 mm-300 mm
focal length (video)	32.4 mm-360 mm
minimum focus distance	1 ft (wide end) - 1.6 ft (tele end)
angle of view	76°
maximum aperture (wide end)	F3.5
maximum aperture (tele end)	F6.3
minimum aperture (wide end)	F22
minimum aperture (tele end)	F40
lens weight	18.5 oz

LCD Display

lcd type	3.0" Xtra Fine LCD, 180° swivel
angle adjustment	Opening: 90°, Turning: 180°
brightness control	Manual (5 steps)

Imaging Sensor

effective picture resolution	14.2 megapixels
imaging sensor size	23.4 x 15.6 mm
pixel gross	14.6 megapixels

Power

battery type	Type V Battery
supplied battery	InfoLITHIUM NP-FV70
battery charger	AC-PW10AM

Weight and Dimensions

weight (body only)	620 g
weight (with battery, lens, and media)	1.3 kg
dimensions (W x H x D)	97 x 132 x 294 mm
