HBD-DZ170/DZ171/DZ175/DZ310/DZ510/DZ610/DZ810
17
2-13. BELT
2-14. MS-203 BOARD
1 two claws
3
belt
2
chuck cam
2 three claws
3
MS-203 board
4
DC motor
1 screw
(M 1.7 u 2.5)
