Sony KD-55X7 E Series User Manual

LDO: +1.05V_M3_STBY
DDC: 3.3V_DDC_OUT check
no
yes
Change IC602
Check EN signal
IC6005 #pin3
Is voltage >3.0V?
START
Check input
C6049 voltage
Is voltage >3.0V?
DDC: 3.3V_DDC_OUT check
no
yes
yes
DDC:3.3V Switching check
no
yes
Change IC605
Check EN signal
IC6018 #pin3
Is voltage >3.0V?
START
Check input
C6124 voltage
Is voltage >3.0V?
DDC: 3.3V Switching check
no
yes
yes
+1.05V_M3_STBY
+1.8V_EMMC
LDO: +1.8V_EMMC
100
3.11 No Power DDCON/LDO
