50
Board
Name
Board PWB (A side) Detail
BB8
3.6 Ethernet – No Connect – Checking Point
50
T7000
J7000
Check any
parts broken
or knock off?
T7001
L7000
RB7000
C7003
Ethernet (B-board Checking) – Checking parts broken or knock off
