DDC: 1.05V_M3_A check
no
yes
Change IC6014
START
Check voltage
C6130
Is voltage >3.0V?
Check EN signal
R6120
Is voltage >3.0V?
yes
no
DDC: 3.3V switching check
DDC: 3.3V switching check
102
3.11 No Power DDCON/LDO
