R4018*
Only measure this
point reference to
GND
R4019*
Only measure this point
reference to GND
3.7.4 HPD Failure Analysis – Measuring point for HPD GPIO line references to ground
HDMI3
HDMI1
HDMI2
R4043*
Only measure this
point reference to
GND
62
62
