2-17. POWER CORD (AC1)
+RZWRLQVWDOOWKHFRUGEXVKLQJ)%6DQGWKHIHUULWHFRUH
2 connector
(CN100)
5 cord bushing
(FBS001)
6 power cord
(AC1)
power cord
clampclamp
SMPS board
1 Remove the wire
from the clamp.
4 ferrite core
(FC1)
ferrite core
3 PEF cushion
(T100)
1 Remove the wire
from the clamp.
3RZHUFRUGVHWWLQJ
rear side
power cord
cord bushing
(FBS001)
to SMPS board
power cord
cord bushing
(FBS001)
ferrite core
265 +5, -0 mm
70 +5, -0 mm
60 +5, -0 mm
PEF cushion
(T100)
86$(3588.
$86($
Ver. 1.1
Note: Ferrite core (Ref. No. FC1) and PEF cushion (T100)
are deleted from the midway of production.
(E3, E12, E32, E51, MX, BR, SP)
