HT-GT1
HT-GT1
4242
• Waveforms
– MAIN Board –
59.4 ns
3.2 Vp-p
1
IC1002 qg (XOUT_PLL)
1 V/DIV, 20 ns/DIV
22.7 Ps
3.7 Vp-p
2
IC1002 wg (LRCK)
1 V/DIV, 10 Ps/DIV
3
IC1002 wh (BCK)
1 V/DIV, 200 ns/DIV
356 ns
4.1 Vp-p
400 Ps
3.8 Vp-p
4
IC1006 qk (LRCK)
1 V/DIV, 200 Ps/DIV
5
IC1006 ql (BCK)
1 V/DIV, 2 Ps/DIV
6.2 Ps
4 Vp-p
6
IC1006 r; (XTO)
1 V/DIV, 20 ns/DIV
40.4 ns
2.7 Vp-p
7
IC1008 4 (XTALO)
1 V/DIV, 50 ns/DIV
81 ns
1.9 Vp-p
20.8 Ps
3.7 Vp-p
8
IC1008 ql (LRCLK)
1 V/DIV, 10 Ps/DIV
9
IC1008 wa (MCLKO)
1 V/DIV, 50 ns/DIV
81.5 ns
4.3 Vp-p
0
IC1008 ws (SCLKOUT1)
1 V/DIV, 100 ns/DIV
326 ns
4.2 Vp-p
qa
IC1008 wd (SCLKOUT2)
1 V/DIV, 100 ns/DIV
326 ns
4.2 Vp-p
qd
IC3001 qa (Xout)
1 V/DIV, 100 ns/DIV
125 ns
3.1 Vp-p
qs
IC3001 9 (Xcout)
1 V/DIV, 20 Ps/DIV
30.4 Ps
1.8 Vp-p
9.5 Ps
3.4 Vp-p
qf
IC3001 wf (DP DRV CLK)
1 V/DIV, 5 Ps/DIV
qg
IC4004 1 (BOOT)
10 V/DIV, 5 Ps/DIV
3.5 Ps
37.6 Vp-p
6-13. PRINTED WIRING BOARD - PANEL Board -
R402
R403
R404
R405
R406
R407
R408
C401
C402
JR401
JR402
IC401
CL401 CL402 CL403 CL404 CL405 CL406
CL407
CL408
CL409 CL410 CL411
CL412
CL413 CL414 CL415 CL416 CL417 CL418 CL419 CL420 CL421 CL422
CL423 CL424 CL425 CL426 CL434
CL427 CL428 CL429 CL430 CL431 CL432
CL433
CL435
CL436
CL437
CL438
CL439
CL440
CL441
CL442
CL443
CL444
Q401
CL445
CL446
CL447
CL448
CL449
CL450
CL451
CL452
CL453
CL454
CL455
CL456
CL457
CL458
CL459
212
113
36 1
61
CN401
CN402
JW401
JW402
JW403
JW405 JW406JW407
D401
D401
(LCD BACK LIGHT)
ND401
LIQUID CRYSTAL DISPLAY
14
13
39
40
26
1
27
52
PANEL BOARD
1-893-768-
11, 12
(11, 12)
E
BUTTON BOARD
CN301
>07P
MAIN BOARD
CN3004
>02P
A
B
1 2 3 4 5
FFC1
(Page 38)
(Page 40)
• : Uses unleaded solder.
• See page 32 for Circuit Boards Location.
Ver. 1.1
