Sony STR-DE695 Service Manual

51
STR-DE695
SECTION 6
ELECTRICAL PARTS LIST
NOTE:
• Due to standardization, replacements in
the parts list may be different from the
parts specified in the diagrams or the
components used on the set.
• RESISTORS
All resistors are in ohms.
METAL:Metal-film resistor.
METAL OXIDE: Metal oxide-film resistor.
F:nonflammable
• Items marked “*” are not stocked since
they are seldom required for routine service.
Some delay should be anticipated
when ordering these items.
• SEMICONDUCTORS
In each case, u : µ, for example:
uA.. : µA.. uPA.. : µPA..
uPB.. : µPB.. uPC.. : µPC.. uPD.. : µPD..
• CAPACITORS
uF : µF
• COILS
uH : µH
•Abbreviation
CND : Canadian model
AUS: Australian model
E2 : AC 120 V area in E model
E3 : AC 240 V area in E model
JE : Tourist model
SP : Singapore model
MY : Malaysia model
TW : Taiwan model
AR : Argentina model
MX : Mexican model
CH : Chinese model
Ref. No. Part No. Description Remark Ref. No. Part No. Description Remark
1-687-154-11 AC SELECT BOARD (E2,E3,JE)
****************
< CONNECTOR >
* CNP910 1-564-687-11 PIN, CONNECTOR (3.96mm PITCH) 3P
(E2,E3,JE)
< SWITCH >
0 S901 1-571-437-21 SWITCH, POWER VOLTAGE CHANGE
(VOLTAGE SELECTOR) (E2,E3,JE)
*************************************************************
A-4731-528-A DIGITAL BOARD, COMPLETE (US,CND)
A-4731-680-A DIGITAL BOARD, COMPLETE (AUS,SP,MY,TW)
A-4731-685-A DIGITAL BOARD, COMPLETE (E2,E3,JE)
A-4731-689-A DIGITAL BOARD, COMPLETE (AR,MX)
A-4731-739-A DIGITAL BOARD, COMPLETE (AEP,UK)
A-4731-756-A DIGITAL BOARD, COMPLETE (CH)
***********************
7-685-646-79 SCREW +BVTP 3X8 TYPE2 IT-3
< CAPACITOR >
C1001 1-126-935-11 ELECT 470uF 20% 10V
C1002 1-164-156-11 CERAMIC CHIP 0.1uF 25V
C1003 1-162-974-11 CERAMIC CHIP 0.01uF 50V
C1011 1-164-156-11 CERAMIC CHIP 0.1uF 25V
C1012 1-126-935-11 ELECT 470uF 20% 10V
C1021 1-164-156-11 CERAMIC CHIP 0.1uF 25V
C1022 1-126-935-11 ELECT 470uF 20% 10V
C1031 1-164-156-11 CERAMIC CHIP 0.1uF 25V
C1032 1-126-935-11 ELECT 470uF 20% 10V
C1063 1-164-156-11 CERAMIC CHIP 0.1uF 25V
(AEP,UK)
C1064 1-126-947-11 ELECT 47uF 20% 25V
(AEP,UK)
C1100 1-164-156-11 CERAMIC CHIP 0.1uF 25V
C1101 1-164-156-11 CERAMIC CHIP 0.1uF 25V
C1102 1-164-156-11 CERAMIC CHIP 0.1uF 25V
C1103 1-126-947-11 ELECT 47uF 20% 35V
C1104 1-164-156-11 CERAMIC CHIP 0.1uF 25V
C1105 1-164-156-11 CERAMIC CHIP 0.1uF 25V
C1106 1-164-156-11 CERAMIC CHIP 0.1uF 25V
C1107 1-164-156-11 CERAMIC CHIP 0.1uF 25V
C1108 1-164-156-11 CERAMIC CHIP 0.1uF 25V
C1109 1-164-156-11 CERAMIC CHIP 0.1uF 25V
C1110 1-164-156-11 CERAMIC CHIP 0.1uF 25V
C1119 1-164-156-11 CERAMIC CHIP 0.1uF 25V
C1120 1-164-156-11 CERAMIC CHIP 0.1uF 25V
C1121 1-164-156-11 CERAMIC CHIP 0.1uF 25V
C1122 1-164-156-11 CERAMIC CHIP 0.1uF 25V
C1123 1-164-156-11 CERAMIC CHIP 0.1uF 25V
C1124 1-164-156-11 CERAMIC CHIP 0.1uF 25V
C1125 1-164-156-11 CERAMIC CHIP 0.1uF 25V
C1126 1-164-816-11 CERAMIC CHIP 220PF 2% 50V
C1127 1-164-156-11 CERAMIC CHIP 0.1uF 25V
C1129 1-162-974-11 CERAMIC CHIP 0.01uF 50V
C1130 1-162-974-11 CERAMIC CHIP 0.01uF 50V
C1131 1-162-974-11 CERAMIC CHIP 0.01uF 50V
C1132 1-162-974-11 CERAMIC CHIP 0.01uF 50V
C1133 1-162-974-11 CERAMIC CHIP 0.01uF 50V
C1134 1-162-974-11 CERAMIC CHIP 0.01uF 50V
C1137 1-162-974-11 CERAMIC CHIP 0.01uF 50V
C1138 1-164-156-11 CERAMIC CHIP 0.1uF 25V
C1139 1-164-156-11 CERAMIC CHIP 0.1uF 25V
C1141 1-164-156-11 CERAMIC CHIP 0.1uF 25V
C1142 1-164-156-11 CERAMIC CHIP 0.1uF 25V
C1251 1-164-156-11 CERAMIC CHIP 0.1uF 25V
C1252 1-164-156-11 CERAMIC CHIP 0.1uF 25V
C1253 1-164-156-11 CERAMIC CHIP 0.1uF 25V
C1254 1-164-816-11 CERAMIC CHIP 220PF 2% 50V
C1255 1-164-816-11 CERAMIC CHIP 220PF 2% 50V
C1256 1-164-816-11 CERAMIC CHIP 220PF 2% 50V
C1301 1-164-156-11 CERAMIC CHIP 0.1uF 25V
C1302 1-162-974-11 CERAMIC CHIP 0.01uF 50V
C1303 1-164-156-11 CERAMIC CHIP 0.1uF 25V
C1304 1-162-974-11 CERAMIC CHIP 0.01uF 50V
C1305 1-164-156-11 CERAMIC CHIP 0.1uF 25V
C1306 1-126-947-11 ELECT 47uF 20% 35V
C1308 1-164-156-11 CERAMIC CHIP 0.1uF 25V
C1309 1-162-918-11 CERAMIC CHIP 18PF 5% 50V
C1310 1-162-918-11 CERAMIC CHIP 18PF 5% 50V
C1312 1-164-156-11 CERAMIC CHIP 0.1uF 25V
C1313 1-162-927-11 CERAMIC CHIP 100PF 5% 50V
C1314 1-164-156-11 CERAMIC CHIP 0.1uF 25V
C1315 1-162-974-11 CERAMIC CHIP 0.01uF 50V
C1316 1-164-156-11 CERAMIC CHIP 0.1uF 25V
C1317 1-126-935-11 ELECT 470uF 20% 10V
C1351 1-164-156-11 CERAMIC CHIP 0.1uF 25V
C1352 1-164-156-11 CERAMIC CHIP 0.1uF 25V
DIGITAL
When indicating parts by reference
number, please include the board.
The components identified by mark 0 or
dotted line with mark 0 are critical for
safety.
Replace only with part number specified.
Les composants identifiés par une marque
0 sont critiques pour la sécurité.
Ne les remplacer que par une piéce portant
le numéro spécifié.
AC SELECT
Ver 1.1
