Sony STR-DE695 Service Manual

56
STR-DE695
Ref. No. Part No. Description Remark Ref. No. Part No. Description Remark
R1532 1-216-813-11 METAL CHIP 220 5% 1/10W
R1533 1-216-813-11 METAL CHIP 220 5% 1/10W
R1534 1-216-813-11 METAL CHIP 220 5% 1/10W
R1535 1-216-813-11 METAL CHIP 220 5% 1/10W
R1536 1-216-813-11 METAL CHIP 220 5% 1/10W
R1537 1-216-813-11 METAL CHIP 220 5% 1/10W
R1538 1-216-813-11 METAL CHIP 220 5% 1/10W
R1539 1-216-813-11 METAL CHIP 220 5% 1/10W
R1540 1-216-813-11 METAL CHIP 220 5% 1/10W
R1541 1-216-813-11 METAL CHIP 220 5% 1/10W
R1542 1-216-813-11 METAL CHIP 220 5% 1/10W
R1543 1-216-813-11 METAL CHIP 220 5% 1/10W
R1544 1-216-813-11 METAL CHIP 220 5% 1/10W
R1545 1-216-813-11 METAL CHIP 220 5% 1/10W
R1546 1-216-813-11 METAL CHIP 220 5% 1/10W
R1547 1-216-813-11 METAL CHIP 220 5% 1/10W
R1548 1-216-813-11 METAL CHIP 220 5% 1/10W
R1549 1-216-813-11 METAL CHIP 220 5% 1/10W
R1550 1-216-813-11 METAL CHIP 220 5% 1/10W
R1551 1-216-813-11 METAL CHIP 220 5% 1/10W
R1552 1-216-813-11 METAL CHIP 220 5% 1/10W
R1553 1-216-813-11 METAL CHIP 220 5% 1/10W
R1554 1-216-813-11 METAL CHIP 220 5% 1/10W
R1555 1-216-813-11 METAL CHIP 220 5% 1/10W
R1556 1-216-809-11 METAL CHIP 100 5% 1/10W
R1570 1-216-833-11 METAL CHIP 10K 5% 1/10W
R1571 1-216-833-11 METAL CHIP 10K 5% 1/10W
R1572 1-216-833-11 METAL CHIP 10K 5% 1/10W
R1573 1-216-833-11 METAL CHIP 10K 5% 1/10W
R1574 1-216-833-11 METAL CHIP 10K 5% 1/10W
< VIBRATOR >
X1101 1-795-179-21 VIBRATOR, CERAMIC (16.5MHz)
X1301 1-795-126-21 VIBRATOR, CRYSTAL (12.288MHz)
X1502 1-781-527-21 VIBRATOR, CRYSTAL (13.5MHz)
*************************************************************
A-4731-521-A DISPLAY BOARD, COMPLETE (US,CND,MX)
A-4731-672-A DISPLAY BOARD, COMPLETE
(EXCEPT US,CND,CH,MX)
A-4731-750-A DISPLAY BOARD, COMPLETE (CH)
************************
* 3-386-245-13 HOLDER (FL)
* 4-921-941-01 CUSHION (FL)
< CAPACITOR >
C100 1-164-159-11 CERAMIC 0.1uF 50V
C101 1-164-159-11 CERAMIC 0.1uF 50V
C104 1-164-159-11 CERAMIC 0.1uF 50V
C105 1-126-795-11 ELECT 10uF 20% 50V
C108 1-164-159-11 CERAMIC 0.1uF 50V
C109 1-164-159-11 CERAMIC 0.1uF 50V
C110 1-128-825-11 CERAMIC 0.0022uF 5% 50V
C111 1-128-809-11 CERAMIC 100PF 5% 50V
C112 1-128-809-11 CERAMIC 100PF 5% 50V
C114 1-164-159-11 CERAMIC 0.1uF 50V
C115 1-126-795-11 ELECT 10uF 20% 50V
C132 1-128-813-11 CERAMIC 220PF 5% 50V
C133 1-128-813-11 CERAMIC 220PF 5% 50V
C134 1-128-813-11 CERAMIC 220PF 5% 50V
C135 1-128-813-11 CERAMIC 220PF 5% 50V
C136 1-128-813-11 CERAMIC 220PF 5% 50V
C137 1-128-813-11 CERAMIC 220PF 5% 50V
C138 1-128-813-11 CERAMIC 220PF 5% 50V
C139 1-128-813-11 CERAMIC 220PF 5% 50V
C140 1-128-813-11 CERAMIC 220PF 5% 50V
C141 1-128-813-11 CERAMIC 220PF 5% 50V
C142 1-128-813-11 CERAMIC 220PF 5% 50V
C143 1-128-813-11 CERAMIC 220PF 5% 50V
C144 1-164-159-11 CERAMIC 0.1uF 50V
C150 1-164-159-11 CERAMIC 0.1uF 50V
C151 1-126-795-11 ELECT 10uF 20% 50V
C155 1-164-159-11 CERAMIC 0.1uF 50V
C156 1-164-159-11 CERAMIC 0.1uF 50V
C157 1-164-159-11 CERAMIC 0.1uF 50V
< CONNECTOR >
CNS100 1-568-742-11 SOCKET, CONNECTOR 23P
< DIODE >
D101 8-719-084-07 LED SEL5E20C-TP15
(MULTI CHANNEL DECODING)
D102 8-719-046-39 LED SEL5821A-TP15 (MUSIC)
D103 8-719-046-39 LED SEL5821A-TP15 (MOVIE)
D104 8-719-046-39 LED SEL5821A-TP15 (A.F.D.)
D105 8-719-046-39 LED SEL5821A-TP15 (2CH)
D106 8-719-046-39 LED SEL5821A-TP15 (SURR BACK DECODING)
< FLUORESCENT INDICATOR >
FL101 1-518-831-11 INDICATOR TUBE, FLUORESCENT
< IC >
IC100 8-759-643-83 IC uPD16315GB-3BS
IC101 8-759-036-90 IC MC74ACT08N
IC102 6-600-055-01 IC GP1UD27SXK (IR)
< COIL >
L101 1-412-473-21 INDUCTOR (SMALL TYPE)
L102 1-410-525-11 INDUCTOR 220uH
< TRANSISTOR >
Q100 8-729-119-78 TRANSISTOR 2SC2785-HFE
Q101 8-729-119-78 TRANSISTOR 2SC2785-HFE
< RESISTOR >
R101 1-249-417-11 CARBON 1K 5% 1/4W
R102 1-249-421-11 CARBON 2.2K 5% 1/4W
R103 1-249-421-11 CARBON 2.2K 5% 1/4W
R104 1-249-425-11 CARBON 4.7K 5% 1/4W
R105 1-249-429-11 CARBON 10K 5% 1/4W
R106 1-249-433-11 CARBON 22K 5% 1/4W
R107 1-249-437-11 CARBON 47K 5% 1/4W
R111 1-249-417-11 CARBON 1K 5% 1/4W
R112 1-249-421-11 CARBON 2.2K 5% 1/4W
R113 1-249-421-11 CARBON 2.2K 5% 1/4W
DISPLAYDIGITAL
Ver 1.1

Sony STR-DE695 Specifications

General

Dimensions (WxDxH)	430 x 310 x 157 mm
Power requirements	230 V; 50/60 Hz
Supported radio bands	FM, MW
Radio Data System (RDS)	Yes
I/O ports	5.1 Analogue Input - 1.0 Audio Input - 3.0 Audio Input Front - 1 Audio Output - 1.0 Control A1 / A1 II Digital Input: coaxial - 1.0 Digital Input: optical - 3.0 Digital Output: optical - 1.0 Headphone Output Monitor Output (Picture): FBAS - 1.0 Monitor Output (Picture): S-Video - 1.0 Speaker Selector A, B, A+B S-Video Input - 3.0 S-Video Output- 1.0 Video Input - 4.0 Video Output - 1.0
Connectivity technology	Wired
Power consumption (standby)	0.3 W
Power consumption (typical)	250 W

Weight and Dimensions

Weight	8500 g
