1-6. Tools and Fixtures
The following tools are prepared for the XVS-9000/XVS-8000/XVS-7000/XVS-6000.
Tool name Part number Use
Extension board
EX-1132B
A-2117-750-A Used to extend the following front boards.
CA-92, CA-92A, OUT-38/38A, MIX-57, VPR-129/129A, DVP-53A and
DVP-68 board
(Refer to “1-9-1. Extension Board EX-1132B” for using this extension
board)
Extension board
EX-1296
A-2117-749-A Used to extend the following rear boards.
CNI-43, CNI-44, CNI-45, CNI-45A, CNO-43, CNO-44, CNO-44A,
CNO-45, NET-28/28A, NET-32/NET-32A, NET-42/NET-42A/NET-42B
board
(Refer to “1-9-2. Extension Board EX-1296” for using this extension
board)
XVS-9000-C/XVS-8000-C/XVS-7000-C/XVS-6000-C
1-11
